Eclat Storm TA Forks (Thru-Axle)

These forks are designed to be absolutely beefy as and ready for the strees! Ready and raring for the Cortex TA hub!

A stronger, superior modern BMX fork with a fresh look! Taking the legendary éclat Storm Fork as a base, we developed an all-new updated version designed around the introduction of our new thru-axle (TA) hub system. By using a closed style dropout, we were able to create a stiffer and stronger dropout concept which fits the new Cortex 14mm TA front hubs, as well as fitting all of our existing 3/8” bolt female hubs with the supplied adaptors. The fork crown has also been improved upon, by using a larger diameter fork crown with a smooth taper we were able to create a stronger interface between the fork leg and the crown as well as super clean flush transition into the frame head tube. Available in both 15mm and 25mm offsets and covered by our Lifetime Guarantee.

 Specifications:
Material: Full liquid post heat-treated seamless 4130 CrMo
Steerer Length: 170mm, new oversize fork crown for stronger junction
Offset: 25mm
Topbolt: M24 thread, 6061-T6 alloy
Weight: 988g

Features:
• New evolution of the tried and tested Storm Fork
• New-school closed dropout design for superior strength
• For 14mm thru-axle (TA) hubs or female front hubs with 3/8″ bolts (adaptors included)
• Oversize fork crown for improved leg junction
• Flush fit with frame head tube
• 2.4″ tyre clearance

Machining:
• Fully CNC’d steerer and butted fork blades
• Integrated crown race
• Mechanically formed fork leg
• Designed for integrated 45° headsets
• CNC recess for 10 mm adaptor

Dropouts:
• Thru-axle / female axle-specific closed dropout
• CNC machined laser cut 5mm thick
• Heat-treated 4130 CrMo
• For 14mm thru-axle or 3/8″ female bolt hubs
• 3/8″ adaptors included

Topbolt:
M24 thread, 6061-T6 alloy

Weight:
15mm – 988g (34.1oz : 2.17lbs)

*Not compatible with male axle front hubs, will fit most 3/8″ female bolt hubs and 14mm thru-axle (TA) front hubs*
