Fit Shiv V3 Forks

The main goal with the Shiv V3 Fork for Fit Bike co was to design and produce an extremely strong fork with plenty of tire clearance. After 2 years of RandD and a lot of investment in tooling, the Shiv V3 is available with a quick 25mm offset. Here are a few features that make these forks so strong. Using left and right specific investment cast drop-outs instead of traditional Cr-Mo plate, Fit have eliminated the weld gap on the inside of the drops, and were able to thicken up the drops toward the top making a much stronger drop-out/leg connection. Seamless, swaged legs provide more strength than welded or fused caps-especially if pegs are installed. The ends of these legs are formed, not capped and welded so there is nothing to fracture. A longer 166mm CNC’d steerer tube with increased wall thicknesses wherever possible and a 24mm x 1.5 compression cap with integrated race. Tapered and butted legs provide tons of strength, crown weld surface, and peg clearance./li> Post weld 4Q Baked heat-treatment

• Legs
• Dropouts
• Steerer Tube
• Steerer Tube Length
• Compression
• Axle to Crown
• Offset
• Weight
• Heat Treat

• Seamless Swaged (No Welded Cap)
• Investment Cast
• 1 Piece CNC-Machined 4130 CrMo
• 166mm
• M24 X 1.5 Thread – 6mm Allen Slot
• 320mm
• 25mm
• 2.25 lb (1.02 kg)
• 4Q Baked Post-Weld
